Protocol independent message processessing state. More...

Collaboration diagram for Protocol Message State:

Data Structures
struct	xml_msg_hdr_t
	Common Encoding Message Header No longer XML specific!! Used by JSON and CBOR parsing as well!! Allows common rendering and error handlers. More...

Macros
#define	XML_MSG_FL_PREFIX bit0
	xml_msg_hdr_t flags field bit definitions start here if PREFIX set then prefixes will be used for element start and end tags. More...

#define	XML_MSG_FL_ETAGS bit1
	indicates that EntityTags (etag attribute) should be generated

#define	XML_MSG_FL_ETAGS_TEST bit2
	indicates the ETag test sense 1= if_match, 0= if_none_match

#define	XML_MSG_FL_TSTAMPS bit3
	indicates that Last-Modified timestamps (last-modified attribute) should be generated

#define	XML_MSG_FL_TSTAMPS_TEST bit4
	indicates the Tstamps test sense 1= modified_since, 0= unmodified_since

#define	XML_MSG_FL_KEYS bit5
	indicates that keys-only is selected for the retrieval output

#define	XML_MSG_FL_PASSED bit6
	indicates that the last-modified test has passed at least once

#define	XML_MSG_FL_DELTA bit7
	indicates that IfModifiedSince and IfUnmodifiedSince filters cause only the changed nodes to be returned More...

#define	XML_MSG_FL_OWNERS bit8
	indicates that with-owners attribute should be added to reply for a <get>, <get-config>, <copy-config>

#define	XML_MSG_FL_GET2 bit9
	indicates that get2 object-based retrieval is active for this reply for a <get>

#define	XML_MSG_FL_MODTAGS bit10
	indicates that module-tags were provided in the get or get-config

#define	XML_MSG_FL_MODTAGS_EMPTY bit11
	indicates that module-tags were provided and none are valid

#define	XML_MSG_FL_ANYXML_TRACK bit12
	indicates anyxml object tracking is in progress

#define	XML_MSG_USE_PREFIX(M) ((M)->flags & XML_MSG_FL_PREFIX)
	Set the message flag to use XML prefixes.

#define	XML_MSG_NO_PREFIX(M) ((M)->flags &= ~XML_MSG_FL_PREFIX)
	Clear the message flag to use XML prefixes.

#define	XML_MSG_WITH_ETAGS(M) ((M)->flags & XML_MSG_FL_ETAGS)
	Check if ETags should be returned.

#define	XML_MSG_WITH_ETAGS_TEST(M) ((M)->flags & XML_MSG_FL_ETAGS_TEST)
	Check if ETags Test should be returned.

#define	XML_MSG_SET_WITH_ETAGS(M) (M)->flags \|= XML_MSG_FL_ETAGS
	Set flag that ETags should be returned.

#define	XML_MSG_SET_WITH_ETAGS_TEST(M) (M)->flags \|= XML_MSG_FL_ETAGS_TEST
	Set flag that ETags Test should be returned.

#define	XML_MSG_CLR_WITH_ETAGS_TEST(M) (M)->flags &= ~XML_MSG_FL_ETAGS_TEST
	Clear flag that ETags Test should be returned.

#define	XML_MSG_WITH_TSTAMPS(M) ((M)->flags & XML_MSG_FL_TSTAMPS)
	Check if timestamps should be returned.

#define	XML_MSG_WITH_TSTAMPS_TEST(M) ((M)->flags & XML_MSG_FL_TSTAMPS_TEST)
	Check if timestamps Test should be returned.

#define	XML_MSG_SET_WITH_TSTAMPS(M) (M)->flags \|= XML_MSG_FL_TSTAMPS
	Set flag that timestamps should be returned.

#define	XML_MSG_SET_WITH_TSTAMPS_TEST(M) (M)->flags \|= XML_MSG_FL_TSTAMPS_TEST
	Set flag that timestamps Test should be returned.

#define	XML_MSG_CLR_WITH_TSTAMPS_TEST(M) (M)->flags &= ~XML_MSG_FL_TSTAMPS_TEST
	Clear flag that timestamps Test should be returned.

#define	XML_MSG_TSTAMPS_PASSED(M) ((M)->flags & XML_MSG_FL_PASSED)
	Check if timestamps test passed.

#define	XML_MSG_SET_TSTAMPS_PASSED(M) (M)->flags \|= XML_MSG_FL_PASSED
	Set flag that timestamps test passed.

#define	XML_MSG_DELTA(M) ((M)->flags & XML_MSG_FL_DELTA)
	Get delta: Not currently used - enables sub-tree time-filtering.

#define	XML_MSG_SET_DELTA(M) (M)->flags \|= XML_MSG_FL_DELTA
	Set Delta: Not currently used - enables sub-tree time-filtering.

#define	XML_MSG_KEYS_ONLY(M) ((M)->flags & XML_MSG_FL_KEYS)
	Check flag that KEYS-ONLY mode is requested (TBD)

#define	XML_MSG_SET_KEYS_ONLY(M) (M)->flags \|= XML_MSG_FL_KEYS
	Set flag that that KEYS-ONLY mode is requested (TBD)

#define	XML_MSG_WITH_OWNERS(M) ((M)->flags & XML_MSG_FL_OWNERS)
	Check if NDMA owner attributes requested.

#define	XML_MSG_SET_WITH_OWNERS(M) (M)->flags \|= XML_MSG_FL_OWNERS
	Set flag that NDMA owner attributes requested.

#define	XML_MSG_CLR_WITH_OWNERS(M) (M)->flags &= ~XML_MSG_FL_OWNERS
	Clear flag that NDMA owner attributes requested.

#define	XML_MSG_WITH_GET2(M) ((M)->flags & XML_MSG_FL_GET2) ? TRUE : FALSE
	Check if GET2 mode requested.

#define	XML_MSG_SET_WITH_GET2(M) (M)->flags \|= XML_MSG_FL_GET2
	Set flag that GET2 mode requested.

#define	XML_MSG_CLR_WITH_GET2(M) (M)->flags &= ~XML_MSG_FL_GET2
	Clear flag that GET2 mode requested.

#define	XML_MSG_SET_LOOKUPQ(M, Q) (M)->lookupQ = Q
	Set GET2 lookup entry.

#define	XML_MSG_SET_MATCHQ(M, Q) (M)->matchQ = Q
	Set GET2 matchQ entry.

#define	XML_MSG_SET_SELECTQ(M, Q) (M)->selectQ = Q
	Set GET2 selectQ entry.

#define	XML_MSG_ANYXML_TRACK(M) ((M)->flags & XML_MSG_FL_ANYXML_TRACK)
	Check if anyxml tracking is active.

#define	XML_MSG_SET_ANYXML_TRACK(M) (M)->flags \|= XML_MSG_FL_ANYXML_TRACK
	Set flag that anyxml tracking is active.

#define	XML_MSG_CLR_ANYXML_TRACK(M) (M)->flags &= ~XML_MSG_FL_ANYXML_TRACK
	Clear flag that anyxml tracking is active.

#define	XML_MSG_ANYXML_OBJ(M) (M)->anyxml_obj
	Access the anyxml tracking object.

#define	XML_MSG_GET_ERROR_DATAQ(M) &(M)->error_dataQ
	Get USER ERROR DATA Q.

#define	XML_MSG_ACTIONVAL(M) (M)->actionval
	Get YANG 1.1 action value node.

#define	XML_MSG_GETBULK(M) (M)->getbulk_cb
	NETCONF <get-bulk> support.

#define	XML_MSG_GET2_TARGET(M) (M)->get2_target
	GET2 request target terminal node.

#define	XML_MSG_GET2CB(M) (M)->get2cb
	GET2 control block backptr.

#define	XML_MSG_WITH_MODTAGS(M) ((M)->flags & XML_MSG_FL_MODTAGS)
	Check if module-tags filtering requested.

#define	XML_MSG_SET_WITH_MODTAGS(M) (M)->flags \|= XML_MSG_FL_MODTAGS
	Set flag that module-tags filtering requested.

#define	XML_MSG_WITH_MODTAGS_EMPTY(M) ((M)->flags & XML_MSG_FL_MODTAGS_EMPTY)
	Check if empty module-tags set.

#define	XML_MSG_SET_WITH_MODTAGS_EMPTY(M) (M)->flags \|= XML_MSG_FL_MODTAGS_EMPTY
	Set flag that empty module-tags return set.

#define	XML_MSG_YPGNMI_GETCB(M) (M)->gnmi_getcb
	YP-gNMI <get> support.

#define	XML_MSG_YPGNMI_EDITCB(M) (M)->gnmi_editcb
	YP-gNMI <set> support.

#define	XML_MSG_PRUNE_BAD_DATA(M) (M)->prune_bad_data
	prune bad data

#define	XML_MSG_XGET_REQ(M) (M)->xget_request
	<get> for XPath filter

#define	XML_MSG_ALLINONE_MODE(M) (M)->all_in_one_mode
	AIO params.

#define	XML_MSG_LAST_GET2_FILPTR(M) (M)->get2_filptr
	The last GET2 Filter Pointer; may be used in case there are some AIO nodes still left.

#define	XML_MSG_GET2CB_ALLINONE(M) (M)->get2cb
	GET2 control block backptr to be used in AIO mode.

#define	XML_MSG_NMDA_PARAMS(M) (M)->nmda_params
	NMDA params.

#define	XML_MSG_WITH_ORIGIN(M) ((M)->nmda_params && (M)->nmda_params->with_origin)
	NMDA with-origin requested.

#define	XML_MSG_EDIT_CONFIG_ROOT(M) (M)->edit_config_root
	NACM data rule support to test incoming message <config>

#define	XML_MSG_DEPTH_TARGET(M) (M)->depth_target
	GET2 depth target for the level 1 node.

#define	XML_MSG_NMDA_OPERATIONAL(M)
	NMDA <operational> requested.

#define	XML_MSG_SM_MPID(M) (M)->sm_mpid
	the schema mount MPID active in the request will be NULL unless WITH_SCHEMA_MOUNT=1 and also ncx_get_sm_active() is true. More...

#define	XML_MSG_SID_LOWER(M) (M)->sid_lower
	YANG SID FILTER LOWER BOUND.

#define	XML_MSG_SID_UPPER(M) (M)->sid_upper
	YANG SID FILTER UPPER BOUND.

#define	XML_MSG_SID_SKIP(M) (M)->sid_skip
	Flag to indicate YANG SID SKIP DATA Mode is active.

#define	XML_MSG_PARENT_SID(M) (M)->parent_sid
	Parent SID in Use if next flag is true.

#define	XML_MSG_ACTION_PARENT(M) (M)->action_parent
	action_parent is the XPath PCB and result for retrieving the actual datastore or state data representing the ancestors of the action node in the incoming <rpc> message

#define	XML_MSG_ACTION_PARENT_MODE(M) (M)->action_parent_mode
	action_parent_mode is TRUE if the XPath request and maybe GET2/AIO requests is for retrieval of the action parent, needed for complex NMDA XPath validation. More...

#define	XML_MSG_SKIP_EMPTY_NPCON(M) (M)->skip_empty_npcon
	flag to indicate the empty NP containers should be skipped. More...

#define	XML_MSG_PRE_PROCESS_MODE(M) (M)->pre_process_mode
	YPW-2272: pre_process_mode is TRUE if Subtree filter is doing Pre process Selection nodes to see if the server should start to write the parent node or not.

Typedefs
typedef void(*	xml_msg_val_error_fn_t) (ses_cb_t scb, xml_msg_hdr_t mhdr, status_t res, val_value_t errnode, const xmlChar badval)
	Record an rpc-error for YANG-API/RESTCONF response translation. More...

typedef void(*	xml_msg_val_errinfo_fn_t) (ses_cb_t scb, xml_msg_hdr_t mhdr, status_t res, val_value_t errnode, const xmlChar badval, const ncx_errinfo_t *errinfo)
	Record an rpc-error for YANG-API/RESTCONF response translation Add errinfo struct if present. More...

typedef void(*	xml_msg_obj_error_fn_t) (ses_cb_t scb, xml_msg_hdr_t mhdr, status_t res, struct obj_template_t_ errobj, const xmlChar badval)
	Record an rpc-error for YANG-API/RESTCONF response translation. More...

typedef boolean(*	xml_msg_authfn_t) (xml_msg_hdr_t msg, const xmlChar username, const val_value_t *val)
	read authorization callback template More...

typedef void(*	xml_msg_record_error_fn_t) (ses_cb_t scb, xml_msg_hdr_t mhdr, ncx_layer_t layer, status_t res, const xml_node_t xmlnode, ncx_node_t parmtyp, const void error_info, ncx_node_t nodetyp, void *error_path)
	Generate an rpc_err_rec_t and save it in the msg. More...

typedef void(*	xml_msg_record_error_errinfo_fn_t) (ses_cb_t scb, xml_msg_hdr_t msghdr, ncx_layer_t layer, status_t res, const xml_node_t xmlnode, ncx_node_t parmtyp, const void error_info, ncx_node_t nodetyp, void error_path, const ncx_errinfo_t errinfo)
	Generate an rpc_err_rec_t and save it in the msg Use the provided error info record for <rpc-error> fields. More...

typedef void(*	xml_msg_record_attr_error_fn_t) (ses_cb_t scb, xml_msg_hdr_t msghdr, ncx_layer_t layer, status_t res, const xml_attr_t xmlattr, const xml_node_t xmlnode, const xmlChar badns, ncx_node_t nodetyp, void errnode)
	Generate an rpc_err_rec_t and save it in the msg. More...

Functions
void	xml_msg_init_hdr (xml_msg_hdr_t *msg)
	Initialize a new xml_msg_hdr_t struct. More...

void	xml_msg_clean_hdr (xml_msg_hdr_t *msg)
	Clean all the memory used by the specified xml_msg_hdr_t but do not free the struct itself. More...

const xmlChar *	xml_msg_get_prefix (xml_msg_hdr_t msg, xmlns_id_t parent_nsid, xmlns_id_t nsid, val_value_t curelem, boolean *xneeded)
	Find the namespace prefix for the specified namespace ID If it is not there then create one. More...

const xmlChar *	xml_msg_get_prefix_xpath (xml_msg_hdr_t *msg, xmlns_id_t nsid)
	Get the module prefix for XPath. More...

const xmlChar *	xml_msg_get_prefix_start_tag (xml_msg_hdr_t *msg, xmlns_id_t nsid)
	Find the namespace prefix for the specified namespace ID. More...

status_t	xml_msg_gen_new_prefix (xml_msg_hdr_t msg, xmlns_id_t nsid, xmlChar *retbuff, uint32 buffsize)
	Generate a new namespace prefix. More...

status_t	xml_msg_build_prefix_map (xml_msg_hdr_t msg, xml_attrs_t attrs, boolean addncid, boolean addncxid)
	Build a queue of xmlns_pmap_t records for the current message. More...

status_t	xml_msg_finish_prefix_map (xml_msg_hdr_t msg, xml_attrs_t attrs)
	Finish the queue of xmlns_pmap_t records for the current message. More...

status_t	xml_msg_check_xmlns_attr (xml_msg_hdr_t msg, xmlns_id_t nsid, const xmlChar badns, xml_attrs_t *attrs)
	Check the default NS and the prefix map in the msg;. More...

status_t	xml_msg_gen_xmlns_attrs (xml_msg_hdr_t msg, xml_attrs_t attrs, boolean addncx)
	Generate any xmlns directives in the top-level attribute Q. More...

status_t	xml_msg_clean_defns_attr (xml_attrs_t *attrs)
	Get rid of an xmlns=foo default attribute. More...

status_t	xml_msg_add_ncid_to_prefix_map (xml_msg_hdr_t msg, xml_attrs_t attrs, xmlns_id_t ncid)
	Add an ncid or ncxid to a prefix map. More...

void	xml_msg_init (void)
	Init this module. More...

void	xml_msg_cleanup (void)
	Cleanup this module. More...

void	xml_msg_set_cfgid (xml_msg_hdr_t *msg, ncx_cfg_t cfgid)
	Set the config ID in the message. More...

ncx_cfg_t	xml_msg_get_cfgid (xml_msg_hdr_t msg, boolean isvalid)
	Set the config ID in the message. More...

uint32	xml_msg_get_msgid (xml_msg_hdr_t *msg)
	Get the message sequence ID in the message. More...

ncx_withdefaults_t	xml_msg_get_withdef (xml_msg_hdr_t *msg)
	Get the message withdef enum. More...

void	xml_msg_set_withdef (xml_msg_hdr_t *msg, ncx_withdefaults_t withdef)
	Set the message withdef enum. More...

uint32	xml_msg_get_max_depth (xml_msg_hdr_t *msg)
	Get the message max_depth value. More...

void	xml_msg_set_max_depth (xml_msg_hdr_t *msg, uint32 max_depth)
	Set the message max_depth value. More...

uint32	xml_msg_get_start_depth (xml_msg_hdr_t *msg)
	Get the message start_depth value. More...

void	xml_msg_set_start_depth (xml_msg_hdr_t *msg, uint32 start_depth)
	Set the message start_depth value. More...

uint32	xml_msg_get_cur_depth (xml_msg_hdr_t *msg)
	Get the message cur_depth value. More...

void	xml_msg_set_cur_depth (xml_msg_hdr_t *msg, uint32 cur_depth)
	Set the message cur_depth value. More...

ncx_display_mode_t	xml_msg_get_encoding (xml_msg_hdr_t *msg, boolean is_output)
	Get the message encoding value. More...

void	xml_msg_set_encoding (xml_msg_hdr_t *msg, boolean is_output, ncx_display_mode_t encoding)
	Set the message encoding value. More...

ncx_etag_t	xml_msg_get_etag (xml_msg_hdr_t msg, boolean test)
	Get the message etag match value and test sense. More...

void	xml_msg_set_etag (xml_msg_hdr_t *msg, ncx_etag_t etag, boolean test_sense)
	Set the etag match parameters. More...

time_t	xml_msg_get_tstamp (xml_msg_hdr_t msg, boolean test)
	Get the message timestamp match value and test sense. More...

void	xml_msg_set_tstamp (xml_msg_hdr_t *msg, time_t tstamp, boolean test_sense)
	Set the timestamp match parameters. More...

dlq_hdr_t *	xml_msg_get_lookupQ (xml_msg_hdr_t *msg)
	Get the GET2 lookup Queue. More...

dlq_hdr_t *	xml_msg_get_matchQ (xml_msg_hdr_t *msg)
	Get the GET2 match Queue. More...

dlq_hdr_t *	xml_msg_get_selectQ (xml_msg_hdr_t *msg)
	Get the GET2 select Queue. More...

void	xml_msg_inc_cur_depth (xml_msg_hdr_t *mhdr)
	Increment the cur_depth parameter if needed. More...

void	xml_msg_dec_cur_depth (xml_msg_hdr_t *mhdr)
	Decrement the cur_depth parameter if needed. More...

boolean	xml_msg_test_max_depth (xml_msg_hdr_t mhdr, const struct obj_template_t_ obj)
	Test the max_depth parameter if needed. More...

void	xml_msg_save_filptr (xml_msg_hdr_t msg, ncx_filptr_t filptr)
	Store current message subtree filter in the Queue for later cleanup. More...

status_t	xml_msg_set_with_origin (xml_msg_hdr_t *mhdr)
	Set the with-origin parameter to true. More...

Detailed Description

Protocol independent message processessing state.

No longer XML only

Deals with generic namespace and xmlns optimization and tries to keep changing the default namespace so most nested elements do not have prefixes.

Deals with the NETCONF requirement that the attributes in <rpc> are returned in <rpc-reply> unchanged. Although XML allows the xnmlns prefixes to change, the same prefixes are used in the <rpc-reply> that the NMS provided in the <rpc>.

NOTE: The xml_msg_hst_t strust is used for both XML and JSON encoding It is no longer XML-specific!!!

Macro Definition Documentation

◆ XML_MSG_ACTION_PARENT_MODE

#define XML_MSG_ACTION_PARENT_MODE ( M ) (M)->action_parent_mode

action_parent_mode is TRUE if the XPath request and maybe GET2/AIO requests is for retrieval of the action parent, needed for complex NMDA XPath validation.

Must make sure that default NP containers are added in this mode. They can be ignored for client retrieval operations but not for NMDA action parent validation

◆ XML_MSG_FL_DELTA

#define XML_MSG_FL_DELTA bit7

indicates that IfModifiedSince and IfUnmodifiedSince filters cause only the changed nodes to be returned

     1 == return just the descendant nodes that match the filter
     0 == return all descendant nodes

◆ XML_MSG_FL_PREFIX

#define XML_MSG_FL_PREFIX bit0

xml_msg_hdr_t flags field bit definitions start here if PREFIX set then prefixes will be used for element start and end tags.

FALSE then default NS will be used so no prefixes will be needed except for XML content with QNames

◆ XML_MSG_SKIP_EMPTY_NPCON

#define XML_MSG_SKIP_EMPTY_NPCON ( M ) (M)->skip_empty_npcon

flag to indicate the empty NP containers should be skipped.

This should only be done on the RPC reply to the client, not YControl messages. Cannot be set to true on subsystems

◆ XML_MSG_SM_MPID

#define XML_MSG_SM_MPID ( M ) (M)->sm_mpid

the schema mount MPID active in the request will be NULL unless WITH_SCHEMA_MOUNT=1 and also ncx_get_sm_active() is true.

Will be present for mounted RPC and action requests

Typedef Documentation

◆ xml_msg_authfn_t

typedef boolean(* xml_msg_authfn_t) (xml_msg_hdr_t *msg, const xmlChar *username, const val_value_t *val)

read authorization callback template

Parameters

msg	message header to use
username	name of the user to check for ccess rights
val	value to check for authorization

Returns: TRUE if access granted; FALSE otherwise

◆ xml_msg_obj_error_fn_t

typedef void(* xml_msg_obj_error_fn_t) (ses_cb_t *scb, xml_msg_hdr_t *mhdr, status_t res, struct obj_template_t_ *errobj, const xmlChar *badval)

Record an rpc-error for YANG-API/RESTCONF response translation.

Parameters

scb	session control block to use
mhdr	message header to use
res	error status code
errobj	object node in API schema tree or data schema tree associated with the error
badval	error-info node to use

◆ xml_msg_record_attr_error_fn_t

typedef void(* xml_msg_record_attr_error_fn_t) (ses_cb_t *scb, xml_msg_hdr_t *msghdr, ncx_layer_t layer, status_t res, const xml_attr_t *xmlattr, const xml_node_t *xmlnode, const xmlChar *badns, ncx_node_t nodetyp, void *errnode)

Generate an rpc_err_rec_t and save it in the msg.

INPUTS:

Parameters

scb	session control block NULL and no stats will be recorded
msghdr	XML msg header with error Q NULL, no errors will be recorded!
layer	netconf layer error occured <error-type>
res	internal error code <error-app-tag>
xmlattr	XML attribute node causing error (NULL if not available)
xmlnode	XML node containing the attr
badns	bad namespace string value
nodetyp	type of node in 'error_path'
errnode	internal data node with the error NULL if not used

◆ xml_msg_record_error_errinfo_fn_t

typedef void(* xml_msg_record_error_errinfo_fn_t) (ses_cb_t *scb, xml_msg_hdr_t *msghdr, ncx_layer_t layer, status_t res, const xml_node_t *xmlnode, ncx_node_t parmtyp, const void *error_info, ncx_node_t nodetyp, void *error_path, const ncx_errinfo_t *errinfo)

Generate an rpc_err_rec_t and save it in the msg Use the provided error info record for <rpc-error> fields.

Parameters

scb	session control block NULL and no stats will be recorded
msghdr	XML msg header with error Q NULL, no errors will be recorded!
layer	netconf layer error occured <error-type>
res	internal error code <error-app-tag>
xmlnode	XML node causing error <bad-element> <error-path> NULL if not available
parmtyp	type of node in 'error_info'
error_info	error data, specific to 'res' <error-info> NULL if not available (then nodetyp ignored)
nodetyp	type of node in 'error_path'
error_path	internal data node with the error <error-path> NULL if not available or not used
errinfo	error info record to use

◆ xml_msg_record_error_fn_t

typedef void(* xml_msg_record_error_fn_t) (ses_cb_t *scb, xml_msg_hdr_t *mhdr, ncx_layer_t layer, status_t res, const xml_node_t *xmlnode, ncx_node_t parmtyp, const void *error_info, ncx_node_t nodetyp, void *error_path)

Generate an rpc_err_rec_t and save it in the msg.

Parameters

	scb	session control block NULL and no stats will be recorded
[in,out]	mhdr	XML msg header with error Q NULL, no errors will be recorded!
	layer	netconf layer error occured <error-type>
	res	internal error code <error-app-tag>
	xmlnode	XML node causing error <bad-element> <error-path> NULL if not available
	parmtyp	type of node in 'error_info'
	error_info	error data, specific to 'res' <error-info> NULL if not available (then nodetyp ignored)
	nodetyp	type of node in 'error_path'
	error_path	internal data node with the error <error-path> NULL if not available or not used

◆ xml_msg_val_errinfo_fn_t

typedef void(* xml_msg_val_errinfo_fn_t) (ses_cb_t *scb, xml_msg_hdr_t *mhdr, status_t res, val_value_t *errnode, const xmlChar *badval, const ncx_errinfo_t *errinfo)

Record an rpc-error for YANG-API/RESTCONF response translation Add errinfo struct if present.

INPUTS:

Parameters

scb	session control block to use
mhdr	xml_msg_hdr_t to use
res	error status code
errnode	node in API tree or data tree associated with the error
badval	error-info string to use
errinfo	ncx_errinfo_t struct to use

◆ xml_msg_val_error_fn_t

typedef void(* xml_msg_val_error_fn_t) (ses_cb_t *scb, xml_msg_hdr_t *mhdr, status_t res, val_value_t *errnode, const xmlChar *badval)

Record an rpc-error for YANG-API/RESTCONF response translation.

Parameters

scb	session control block to use
mhdr	xml_msg_hdr_t to use
res	error status code
errnode	node in API tree or data tree associated with the error
badval	error-info string to use

Function Documentation

◆ xml_msg_add_ncid_to_prefix_map()

status_t xml_msg_add_ncid_to_prefix_map	(	xml_msg_hdr_t *	msg,
		xml_attrs_t *	attrs,
		xmlns_id_t	ncid
	)

Add an ncid or ncxid to a prefix map.

Parameters

msg	the message in progrss
attrs	the the top-level attrs list (e;g, rpc_in_attrs)
ncid	the ncid to add.

Returns: status

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_build_prefix_map()

status_t xml_msg_build_prefix_map	(	xml_msg_hdr_t *	msg,
		xml_attrs_t *	attrs,
		boolean	addncid,
		boolean	addncxid
	)

Build a queue of xmlns_pmap_t records for the current message.

XMLNS Entries for NETCONF and NCX will be added if they are not present

Parameters

[in,out]	msg	message in progress msg->prefixQ will be populated as needed, could be partially populated if some error returned
	attrs	the top-level attrs list (e;g, rpc_in_attrs)
	addncid	TRUE if a prefix entry for the NC namespace should be added FALSE if the NC nsid should not be added
	addncxid	TRUE if a prefix entry for the NCX namespace should be added FALSE if the NCX nsid should not be added

Returns: status

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_check_xmlns_attr()

status_t xml_msg_check_xmlns_attr	(	xml_msg_hdr_t *	msg,
		xmlns_id_t	nsid,
		const xmlChar *	badns,
		xml_attrs_t *	attrs
	)

Check the default NS and the prefix map in the msg;.

XMLNS attr entry may be added to the attrs Q

Parameters

[in,out]	msg	message in progress msg->prefixQ will be populated as needed, could be partially populated if some error returned
	nsid	namespace ID to check
	badns	namespace URI of the bad namespace used if the nsid is the INVALID marker
	attrs	Q to hold the xml_attr_t, if generated

Returns: status

Here is the call graph for this function:

◆ xml_msg_clean_defns_attr()

status_t xml_msg_clean_defns_attr ( xml_attrs_t * attrs )

Get rid of an xmlns=foo default attribute.

Parameters

[in,out]

attrs

xmlns_attrs_t Q to process

*attrs will be cleaned as needed,

Returns: status

Here is the call graph for this function:

◆ xml_msg_clean_hdr()

void xml_msg_clean_hdr ( xml_msg_hdr_t * msg )

Clean all the memory used by the specified xml_msg_hdr_t but do not free the struct itself.

Do NOT reuse this header without calling xml_msg_init_hdr first!!! xml_msg_t headers were originally meant to be used only in other messages, but <hello> messages use the hdr without a wrapper message

Parameters

msg	xml_msg_hdr_t to clean

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_cleanup()

void xml_msg_cleanup ( void )

Cleanup this module.

Here is the caller graph for this function:

◆ xml_msg_dec_cur_depth()

void xml_msg_dec_cur_depth ( xml_msg_hdr_t * mhdr )

Decrement the cur_depth parameter if needed.

Parameters

mhdr	message header to change

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_finish_prefix_map()

status_t xml_msg_finish_prefix_map	(	xml_msg_hdr_t *	msg,
		xml_attrs_t *	attrs
	)

Finish the queue of xmlns_pmap_t records for the current message.

Parameters

[in,out]	msg	message in progrss msg->prefixQ will be populated as needed, could be partially populated if some error returned
	attrs	the top-level attrs list (e;g, rpc_in_attrs)

Returns: status

/param msg message in progrss /param attrs the top-level attrs list (e;g, rpc_in_attrs)

/return status of operation

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_gen_new_prefix()

status_t xml_msg_gen_new_prefix	(	xml_msg_hdr_t *	msg,
		xmlns_id_t	nsid,
		xmlChar **	retbuff,
		uint32	buffsize
	)

Generate a new namespace prefix.

Parameters

	msg	message to search and generate a prefix for
	nsid	namespace ID to generate prefix for
[out]	retbuff	address of return buffer if retbuff is NULL it will be created retbuff is filled in with the new prefix if NO_ERR
	buffsize	buffer size

Returns: status

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_gen_xmlns_attrs()

status_t xml_msg_gen_xmlns_attrs	(	xml_msg_hdr_t *	msg,
		xml_attrs_t *	attrs,
		boolean	addncx
	)

Generate any xmlns directives in the top-level attribute Q.

Parameters

	msg	message in progress
[in,out]	attrs	xmlns_attrs_t Q to process *attrs will be populated as needed,
	addncx	TRUE if an xmlns for the NCX prefix (for errors) should be added to the <rpc-reply> element FALSE if not

Returns: status

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_get_cfgid()

ncx_cfg_t xml_msg_get_cfgid	(	xml_msg_hdr_t *	msg,
		boolean *	isvalid
	)

Set the config ID in the message.

Parameters

	msg	message header to change
[out]	isvalid	address of return valus is valid flag *isvalid TRUE if it has been set; FALSE otherwise

Returns: config ID (ignore if *isvalid is FALSE)

◆ xml_msg_get_cur_depth()

uint32 xml_msg_get_cur_depth ( xml_msg_hdr_t * msg )

Get the message cur_depth value.

Parameters

msg	message header to use

Returns: cur_depth value

Here is the caller graph for this function:

◆ xml_msg_get_encoding()

ncx_display_mode_t xml_msg_get_encoding	(	xml_msg_hdr_t *	msg,
		boolean	is_output
	)

Get the message encoding value.

Parameters

msg	message header to check
is_output	TRUE to get output encoding FALSE to get input encoding

Returns: encoding enumeration

◆ xml_msg_get_etag()

ncx_etag_t xml_msg_get_etag	(	xml_msg_hdr_t *	msg,
		boolean *	test
	)

Get the message etag match value and test sense.

Parameters

	msg	message header to check
[out]	test	address of return test sense flag *test TRUE for If-Match; FALSE for If-None-Match

Returns: etag value to match

◆ xml_msg_get_lookupQ()

dlq_hdr_t * xml_msg_get_lookupQ ( xml_msg_hdr_t * msg )

Get the GET2 lookup Queue.

Parameters

msg	message header to use

Returns: pointer to lookupQ or NULL if not set

Here is the caller graph for this function:

◆ xml_msg_get_matchQ()

dlq_hdr_t * xml_msg_get_matchQ ( xml_msg_hdr_t * msg )

Get the GET2 match Queue.

Parameters

msg	message header to use

Returns: pointer to matchQ or NULL if not set

◆ xml_msg_get_max_depth()

uint32 xml_msg_get_max_depth ( xml_msg_hdr_t * msg )

Get the message max_depth value.

Parameters

msg	message header to use

Returns: maxdepth value

Here is the caller graph for this function:

◆ xml_msg_get_msgid()

uint32 xml_msg_get_msgid ( xml_msg_hdr_t * msg )

Get the message sequence ID in the message.

Parameters

msg	message header to use

Returns: message ID

◆ xml_msg_get_prefix()

const xmlChar * xml_msg_get_prefix	(	xml_msg_hdr_t *	msg,
		xmlns_id_t	parent_nsid,
		xmlns_id_t	nsid,
		val_value_t *	curelem,
		boolean *	xneeded
	)

Find the namespace prefix for the specified namespace ID If it is not there then create one.

Parameters

	msg	message to search
	parent_nsid	parent namespace ID
	nsid	namespace ID to find
	curelem	value node for current element if available
[out]	xneeded	pointer to xmlns needed flag output value *xneeded TRUE if the prefix is new and an xmlns decl is needed in the element being generated

Returns: pointer to prefix if found, else NULL if not found

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_get_prefix_start_tag()

const xmlChar * xml_msg_get_prefix_start_tag	(	xml_msg_hdr_t *	msg,
		xmlns_id_t	nsid
	)

Find the namespace prefix for the specified namespace ID.

DO NOT CREATE A NEW PREFIX MAP IF IT IS NOT THERE does not create any pfixmap, just returns NULL if not found

Parameters

msg	message to search
nsid	namespace ID to find

Returns: pointer to prefix if found, else NULL if not found

◆ xml_msg_get_prefix_xpath()

const xmlChar * xml_msg_get_prefix_xpath	(	xml_msg_hdr_t *	msg,
		xmlns_id_t	nsid
	)

Get the module prefix for XPath.

Find the namespace prefix for the specified namespace ID If it is not there then create one in the msg prefix map Always returns a prefix, instead of using a default

creates a new pfixmap if needed

  !!! MUST BE CALLED BEFORE THE <rpc-reply> XML OUTPUT
  !!! HAS BEGUN.  CANNOT BE CALLED BY OUTPUT FUNCTIONS
  !!! DURING THE <get> OR <get-config> OUTPUT GENERATION

Parameters

msg	message to search
nsid	namespace ID to find

Returns: pointer to prefix if found, else NULL if not found

Here is the call graph for this function:

◆ xml_msg_get_selectQ()

dlq_hdr_t * xml_msg_get_selectQ ( xml_msg_hdr_t * msg )

Get the GET2 select Queue.

Parameters

msg	message header to use

Returns: pointer to selectQ or NULL if not set

◆ xml_msg_get_start_depth()

uint32 xml_msg_get_start_depth ( xml_msg_hdr_t * msg )

Get the message start_depth value.

Parameters

msg	message header to use

Returns: start-depth value derived from request target URI

Here is the caller graph for this function:

◆ xml_msg_get_tstamp()

time_t xml_msg_get_tstamp	(	xml_msg_hdr_t *	msg,
		boolean *	test
	)

Get the message timestamp match value and test sense.

Parameters

	msg	message header to check
[out]	test	address of return test sense flag test == TRUE for If-Modified-Since test == FALSE for If-Unmodified-Since

Returns: timestamp value to match

◆ xml_msg_get_withdef()

ncx_withdefaults_t xml_msg_get_withdef ( xml_msg_hdr_t * msg )

Get the message withdef enum.

Parameters

msg	message header to use

Returns: with defaults value in the message header

Here is the caller graph for this function:

◆ xml_msg_inc_cur_depth()

void xml_msg_inc_cur_depth ( xml_msg_hdr_t * mhdr )

Increment the cur_depth parameter if needed.

Parameters

mhdr	message header to change

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_init()

void xml_msg_init ( void )

Init this module.

Here is the caller graph for this function:

◆ xml_msg_init_hdr()

void xml_msg_init_hdr ( xml_msg_hdr_t * msg )

Initialize a new xml_msg_hdr_t struct.

Parameters

msg	xml_msg_hdr_t memory to initialize

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_save_filptr()

void xml_msg_save_filptr	(	xml_msg_hdr_t *	msg,
		ncx_filptr_t *	filptr
	)

Store current message subtree filter in the Queue for later cleanup.

Get2 may try to access some of the fields from this structure

GET2 will run multiple invoke_get2 callbacks which will try to use this filptr.

Parameters

msg	message to use
filptr	filter pointer to add

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_set_cfgid()

void xml_msg_set_cfgid	(	xml_msg_hdr_t *	msg,
		ncx_cfg_t	cfgid
	)

Set the config ID in the message.

Parameters

msg	message header to change
cfgid	configuration ID to use

◆ xml_msg_set_cur_depth()

void xml_msg_set_cur_depth	(	xml_msg_hdr_t *	msg,
		uint32	cur_depth
	)

Set the message cur_depth value.

Parameters

msg	message header to set
cur_depth	new depth value

Here is the caller graph for this function:

◆ xml_msg_set_encoding()

void xml_msg_set_encoding	(	xml_msg_hdr_t *	msg,
		boolean	is_output,
		ncx_display_mode_t	encoding
	)

Set the message encoding value.

INPUTS:

Parameters

msg	message header to check
is_output	TRUE to set output encoding FALSE to set input encoding
encoding	new encoding value

Here is the caller graph for this function:

◆ xml_msg_set_etag()

void xml_msg_set_etag	(	xml_msg_hdr_t *	msg,
		ncx_etag_t	etag,
		boolean	test_sense
	)

Set the etag match parameters.

Parameters

msg	message header to set
etag	etag to match
test_sense	TRUE to match, FALSE for none-match

Here is the caller graph for this function:

◆ xml_msg_set_max_depth()

void xml_msg_set_max_depth	(	xml_msg_hdr_t *	msg,
		uint32	max_depth
	)

Set the message max_depth value.

Parameters

msg	message header to set
max_depth	number value to set

Here is the caller graph for this function:

◆ xml_msg_set_start_depth()

void xml_msg_set_start_depth	(	xml_msg_hdr_t *	msg,
		uint32	start_depth
	)

Set the message start_depth value.

Parameters

msg	message header to set
start_depth	number value to set

Here is the caller graph for this function:

◆ xml_msg_set_tstamp()

void xml_msg_set_tstamp	(	xml_msg_hdr_t *	msg,
		time_t	tstamp,
		boolean	test_sense
	)

Set the timestamp match parameters.

Parameters

msg	message header to set
tstamp	timestamp to match
test_sense	TRUE to modified-since, FALSE for unmodified-since

Here is the caller graph for this function:

◆ xml_msg_set_with_origin()

status_t xml_msg_set_with_origin ( xml_msg_hdr_t * mhdr )

Set the with-origin parameter to true.

Parameters

mhdr	message header to set

Returns: status

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xml_msg_set_withdef()

void xml_msg_set_withdef	(	xml_msg_hdr_t *	msg,
		ncx_withdefaults_t	withdef
	)

Set the message withdef enum.

Parameters

msg	message header to set
withdef	enum value to set

Here is the caller graph for this function:

◆ xml_msg_test_max_depth()

boolean xml_msg_test_max_depth	(	xml_msg_hdr_t *	mhdr,
		const struct obj_template_t_ *	obj
	)

Test the max_depth parameter if needed.

Needed by GET2 walker functions to determine if the max depth has been reached (because <depth> parameter used in GET) The depth level does not follow the object schema level obj_get_level() It is defined in RFC 8040 to usually be the target resource node.

Parameters

[in,out]	mhdr	message header to check mhdr->cur_depth may get changed to 0 or 1 if mhdr->depth_target and obj set
	obj	object that is about to be rendered and testing max_depth This will bec checked against the msg->depth_target if set This object is the real level 1 NULL to ignore depth_target

Returns: TRUE if last level has been reached
FALSE if normal output mode

Here is the call graph for this function:

Here is the caller graph for this function:

Data Structures

Macros

Typedefs

Functions

Detailed Description

Macro Definition Documentation

◆ XML_MSG_ACTION_PARENT_MODE

◆ XML_MSG_FL_DELTA

◆ XML_MSG_FL_PREFIX

◆ XML_MSG_SKIP_EMPTY_NPCON

◆ XML_MSG_SM_MPID

Typedef Documentation

◆ xml_msg_authfn_t

◆ xml_msg_obj_error_fn_t

◆ xml_msg_record_attr_error_fn_t

◆ xml_msg_record_error_errinfo_fn_t

◆ xml_msg_record_error_fn_t

◆ xml_msg_val_errinfo_fn_t

◆ xml_msg_val_error_fn_t

Function Documentation

◆ xml_msg_add_ncid_to_prefix_map()

◆ xml_msg_build_prefix_map()

◆ xml_msg_check_xmlns_attr()

◆ xml_msg_clean_defns_attr()

◆ xml_msg_clean_hdr()

◆ xml_msg_cleanup()

◆ xml_msg_dec_cur_depth()

◆ xml_msg_finish_prefix_map()

◆ xml_msg_gen_new_prefix()

◆ xml_msg_gen_xmlns_attrs()

◆ xml_msg_get_cfgid()

◆ xml_msg_get_cur_depth()

◆ xml_msg_get_encoding()

◆ xml_msg_get_etag()

◆ xml_msg_get_lookupQ()

◆ xml_msg_get_matchQ()

◆ xml_msg_get_max_depth()

◆ xml_msg_get_msgid()

◆ xml_msg_get_prefix()

◆ xml_msg_get_prefix_start_tag()

◆ xml_msg_get_prefix_xpath()

◆ xml_msg_get_selectQ()

◆ xml_msg_get_start_depth()

◆ xml_msg_get_tstamp()

◆ xml_msg_get_withdef()

◆ xml_msg_inc_cur_depth()

◆ xml_msg_init()

◆ xml_msg_init_hdr()

◆ xml_msg_save_filptr()

◆ xml_msg_set_cfgid()

◆ xml_msg_set_cur_depth()

◆ xml_msg_set_encoding()

◆ xml_msg_set_etag()

◆ xml_msg_set_max_depth()

◆ xml_msg_set_start_depth()

◆ xml_msg_set_tstamp()

◆ xml_msg_set_with_origin()

◆ xml_msg_set_withdef()

◆ xml_msg_test_max_depth()
