YANG and other namespaces maintained in a registry. More...

Collaboration diagram for XML Namespace Support:

Data Structures
struct	xmlns_qname_t
	represents one QName data element More...

struct	xmlns_t
	represents one registered namespace More...

struct	xmlns_pmap_t
	represents one namespace prefix mapping More...

Typedefs
typedef uint16	xmlns_id_t
	integer handle for registered namespaces

Functions
void	xmlns_init (void)
	Initialize the module static variables. More...

void	xmlns_cleanup (void)
	Cleanup module static data. More...

status_t	xmlns_register_ns (const xmlChar ns, const xmlChar pfix, const xmlChar modname, void modptr, xmlns_id_t *ns_id)
	Register the specified namespace. More...

void	xmlns_unregister_ns (xmlns_id_t ns_id)
	Unregister the specified namespace. More...

status_t	xmlns_register_temp_ns (const xmlChar ns, const xmlChar pfix, xmlns_id_t *ns_id)
	Register the specified temporary namespace. More...

status_t	xmlns_convert_temp_ns (xmlns_id_t nsid, const xmlChar pfix, const xmlChar modname, void *modptr)
	Register the specified permanent namespace by converting the specified temporary NSID to a permanent entry. More...

const xmlChar *	xmlns_get_ns_prefix (xmlns_id_t ns_id)
	Get the prefix for the specified namespace. More...

const xmlChar *	xmlns_get_ns_name (xmlns_id_t ns_id)
	Get the name for the specified namespace. More...

xmlns_id_t	xmlns_find_ns_by_module (const xmlChar *modname)
	Find the NS ID from its module name that registered it. More...

xmlns_id_t	xmlns_find_ns_by_module_str (const xmlChar *modname, uint32 len)
	Find the NS ID from its module name that registered it. More...

xmlns_id_t	xmlns_find_ns_by_prefix (const xmlChar *pfix)
	Find the NS ID from its prefix. More...

xmlns_id_t	xmlns_find_ns_by_name (const xmlChar *name)
	Find the NS ID from its name. More...

xmlns_id_t	xmlns_find_ns_by_name_str (const xmlChar *name, uint32 namelen)
	Find the NS ID from its name (counted string version) More...

xmlns_id_t	xmlns_nc_id (void)
	Get the ID for the NETCONF namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_ncx_id (void)
	Get the ID for the NETCONF Extensions namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_ns_id (void)
	Get the ID for the XMLNS namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_inv_id (void)
	Get the INVALID namespace ID. More...

xmlns_id_t	xmlns_xs_id (void)
	Get the ID for the XSD namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_xsi_id (void)
	Get the ID for the XSD Instance (XSI) namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_xml_id (void)
	Get the ID for the 1998 XML namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_ncn_id (void)
	Get the ID for the NETCONF Notifications namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_yang_id (void)
	Get the ID for the YANG namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_yin_id (void)
	Get the ID for the YIN namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_wildcard_id (void)
	Get the ID for the base:1.1 wildcard namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_wda_id (void)
	Get the ID for the wd:default XML attribute namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_ywattrs_id (void)
	Get the ID for the YumaWorks attributes namespace or 0 if it doesn't exist. More...

xmlns_id_t	xmlns_origin_id (void)
	Get the ID for the ietf-origin namespace or 0 if it doesn't exist. More...

const xmlChar *	xmlns_get_module (xmlns_id_t nsid)
	get the module name of the namespace ID More...

void *	xmlns_get_modptr (xmlns_id_t nsid)
	get the module pointer for the namespace ID More...

void	xmlns_set_modptrs (const xmlChar modname, void modptr)
	get the module pointer for the namespace ID More...

void	xmlns_clear_modptrs (void *modptr)
	Clear the module pointer for the namespace ID. More...

xmlns_pmap_t *	xmlns_new_pmap (uint32 buffsize)
	malloc and initialize a new xmlns_pmap_t struct More...

void	xmlns_free_pmap (xmlns_pmap_t *pmap)
	free a xmlns_pmap_t struct More...

xmlns_qname_t *	xmlns_new_qname (void)
	malloc and initialize a new xmlns_qname_t struct More...

void	xmlns_free_qname (xmlns_qname_t *qname)
	free a xmlns_qname_t struct More...

boolean	xmlns_ids_equal (xmlns_id_t ns1, xmlns_id_t ns2)
	compare 2 namespace IDs only if they are both non-zero and return TRUE if they are equal More...

void	xmlns_check_deleted_ns (void)
	Check if a deleted namespace is pending and free it. More...

uint16	xmlns_get_mod_count (void)
	Get the total count of the currently loaded modules in the array of the Namespaces. More...

Detailed Description

YANG and other namespaces maintained in a registry.

Function Documentation

◆ xmlns_check_deleted_ns()

void xmlns_check_deleted_ns ( void )

Check if a deleted namespace is pending and free it.

Here is the caller graph for this function:

◆ xmlns_cleanup()

void xmlns_cleanup ( void )

Cleanup module static data.

Here is the caller graph for this function:

◆ xmlns_clear_modptrs()

void xmlns_clear_modptrs ( void * modptr )

Clear the module pointer for the namespace ID.

Parameters

modptr ncx_module_t back-ptr to clear

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_convert_temp_ns()

status_t xmlns_convert_temp_ns	(	xmlns_id_t	nsid,
		const xmlChar *	pfix,
		const xmlChar *	modname,
		void *	modptr
	)

Register the specified permanent namespace by converting the specified temporary NSID to a permanent entry.

Parameters

nsid	namespace id
pfix	namespace prefix to use (if none provided but needed)
modname	name string of module associated with this NS
modptr	back-ptr to ncx_module_t struct (may be NULL)

Returns: status, NO_ERR if all okay

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_find_ns_by_module()

xmlns_id_t xmlns_find_ns_by_module ( const xmlChar * modname )

Find the NS ID from its module name that registered it.

Parameters

modname module name string to find

Returns: namespace ID or XMLNS_NULL_NS_ID if error

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_find_ns_by_module_str()

xmlns_id_t xmlns_find_ns_by_module_str	(	const xmlChar *	modname,
		uint32	len
	)

Find the NS ID from its module name that registered it.

Parameters

modname	module name string to find (NOT Z-TERMINATED)
len	length of modname

Returns: namespace ID or XMLNS_NULL_NS_ID if error

Here is the call graph for this function:

◆ xmlns_find_ns_by_name()

xmlns_id_t xmlns_find_ns_by_name ( const xmlChar * name )

Find the NS ID from its name.

Parameters

name	pointer to name string

Returns: namespace ID or XMLNS_NULL_NS_ID if error

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_find_ns_by_name_str()

xmlns_id_t xmlns_find_ns_by_name_str	(	const xmlChar *	name,
		uint32	namelen
	)

Find the NS ID from its name (counted string version)

Parameters

name	pointer to name string
namelen	length of name string

Returns: namespace ID or XMLNS_NULL_NS_ID if error

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_find_ns_by_prefix()

xmlns_id_t xmlns_find_ns_by_prefix ( const xmlChar * pfix )

Find the NS ID from its prefix.

Parameters

pfix	pointer to prefix string

Returns: namespace ID or XMLNS_NULL_NS_ID if error

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_free_pmap()

void xmlns_free_pmap ( xmlns_pmap_t * pmap )

free a xmlns_pmap_t struct

Parameters

pmap	prefix map struct to free

Here is the caller graph for this function:

◆ xmlns_free_qname()

void xmlns_free_qname ( xmlns_qname_t * qname )

free a xmlns_qname_t struct

Parameters

qname QName struct to free

Here is the caller graph for this function:

◆ xmlns_get_mod_count()

uint16 xmlns_get_mod_count ( void )

Get the total count of the currently loaded modules in the array of the Namespaces.

Returns modules that are not fully loaded (in progress)

Returns: total number of loaded or laading modules

◆ xmlns_get_modptr()

void * xmlns_get_modptr ( xmlns_id_t nsid )

get the module pointer for the namespace ID

Parameters

nsid	namespace ID to check

Returns: void * cast of ncx_module_t * to the module or NULL

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_get_module()

const xmlChar * xmlns_get_module ( xmlns_id_t nsid )

get the module name of the namespace ID

get module name that registered this namespace

Parameters

nsid	namespace ID to check

Returns: module name string

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_get_ns_name()

const xmlChar * xmlns_get_ns_name ( xmlns_id_t ns_id )

Get the name for the specified namespace.

Parameters

ns_id namespace ID

Returns: pointer to name or NULL if bad params

Here is the caller graph for this function:

◆ xmlns_get_ns_prefix()

const xmlChar * xmlns_get_ns_prefix ( xmlns_id_t ns_id )

Get the prefix for the specified namespace.

Parameters

ns_id namespace ID

Returns: pointer to prefix or NULL if bad params

Here is the caller graph for this function:

◆ xmlns_ids_equal()

boolean xmlns_ids_equal	(	xmlns_id_t	ns1,
		xmlns_id_t	ns2
	)

compare 2 namespace IDs only if they are both non-zero and return TRUE if they are equal

Parameters

ns1	namespace ID 1
ns2	namespace ID 2

Returns: TRUE if equal or both IDs are not zero
FALSE if both IDs are non-zero and they are different

Here is the caller graph for this function:

◆ xmlns_init()

void xmlns_init ( void )

Initialize the module static variables.

Here is the caller graph for this function:

◆ xmlns_inv_id()

xmlns_id_t xmlns_inv_id ( void )

Get the INVALID namespace ID.

Returns: INVALID NS ID or 0 if not set yet

Here is the caller graph for this function:

◆ xmlns_nc_id()

xmlns_id_t xmlns_nc_id ( void )

Get the ID for the NETCONF namespace or 0 if it doesn't exist.

Returns: NETCONF NS ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_ncn_id()

xmlns_id_t xmlns_ncn_id ( void )

Get the ID for the NETCONF Notifications namespace or 0 if it doesn't exist.

Returns: NCN ID or 0 if not found

◆ xmlns_ncx_id()

xmlns_id_t xmlns_ncx_id ( void )

Get the ID for the NETCONF Extensions namespace or 0 if it doesn't exist.

Returns: NETCONF-X NS ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_new_pmap()

xmlns_pmap_t * xmlns_new_pmap ( uint32 buffsize )

malloc and initialize a new xmlns_pmap_t struct

Parameters

buffsize size of the prefix buffer to allocate within this pmap (0 == do not malloc yet)

Returns: pointer to new struct or NULL if malloc error

Here is the caller graph for this function:

◆ xmlns_new_qname()

xmlns_qname_t * xmlns_new_qname ( void )

malloc and initialize a new xmlns_qname_t struct

Returns: pointer to new struct or NULL if malloc error

◆ xmlns_ns_id()

xmlns_id_t xmlns_ns_id ( void )

Get the ID for the XMLNS namespace or 0 if it doesn't exist.

Returns: XMLNS NS ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_origin_id()

xmlns_id_t xmlns_origin_id ( void )

Get the ID for the ietf-origin namespace or 0 if it doesn't exist.

Returns: ietf-origin namespace ID or 0 if not loaded

Here is the caller graph for this function:

◆ xmlns_register_ns()

status_t xmlns_register_ns	(	const xmlChar *	ns,
		const xmlChar *	pfix,
		const xmlChar *	modname,
		void *	modptr,
		xmlns_id_t *	ns_id
	)

Register the specified namespace.

Each namespace or prefix can only be registered once. An entry must be removed and added back in order to change it.

Parameters

	ns	namespace name
	pfix	namespace prefix to use (may be NULL)
	modname	name string of module associated with this NS
	modptr	back-ptr to ncx_module_t struct (may be NULL)
[out]	ns_id	address of return NSID *ns_id contains the ID assigned to the namespace

Returns: status, NO_ERR if all okay

Here is the caller graph for this function:

◆ xmlns_register_temp_ns()

status_t xmlns_register_temp_ns	(	const xmlChar *	ns,
		const xmlChar *	pfix,
		xmlns_id_t *	ns_id
	)

Register the specified temporary namespace.

Parameters

	ns	namespace name
	pfix	namespace prefix to use (may be NULL)
[out]	ns_id	address of return NSID *ns_id contains the ID assigned to the namespace

Returns: status, NO_ERR if all okay

Here is the caller graph for this function:

◆ xmlns_set_modptrs()

void xmlns_set_modptrs	(	const xmlChar *	modname,
		void *	modptr
	)

get the module pointer for the namespace ID

Parameters

modname	module owner name to find
modptr	ncx_module_t back-ptr to set

Here is the call graph for this function:

Here is the caller graph for this function:

◆ xmlns_unregister_ns()

void xmlns_unregister_ns ( xmlns_id_t ns_id )

Unregister the specified namespace.

Parameters

ns_id ID of namespace to unregister and free

Here is the caller graph for this function:

◆ xmlns_wda_id()

xmlns_id_t xmlns_wda_id ( void )

Get the ID for the wd:default XML attribute namespace or 0 if it doesn't exist.

Returns: with-defaults default attribute namespace ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_wildcard_id()

xmlns_id_t xmlns_wildcard_id ( void )

Get the ID for the base:1.1 wildcard namespace or 0 if it doesn't exist.

Returns: Wildcard ID or 0 if not found

◆ xmlns_xml_id()

xmlns_id_t xmlns_xml_id ( void )

Get the ID for the 1998 XML namespace or 0 if it doesn't exist.

Returns: XML ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_xs_id()

xmlns_id_t xmlns_xs_id ( void )

Get the ID for the XSD namespace or 0 if it doesn't exist.

Returns: XSD NS ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_xsi_id()

xmlns_id_t xmlns_xsi_id ( void )

Get the ID for the XSD Instance (XSI) namespace or 0 if it doesn't exist.

Returns: XSI ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_yang_id()

xmlns_id_t xmlns_yang_id ( void )

Get the ID for the YANG namespace or 0 if it doesn't exist.

Returns: YANG ID or 0 if not found

Here is the caller graph for this function:

◆ xmlns_yin_id()

xmlns_id_t xmlns_yin_id ( void )

Get the ID for the YIN namespace or 0 if it doesn't exist.

Returns: YIN ID or 0 if not found

◆ xmlns_ywattrs_id()

xmlns_id_t xmlns_ywattrs_id ( void )

Get the ID for the YumaWorks attributes namespace or 0 if it doesn't exist.

Returns: YumaWorks Attrs namespace (yumaworks-attrs.yang)

Here is the caller graph for this function:

Data Structures

Typedefs

Functions

Detailed Description

Function Documentation

◆ xmlns_check_deleted_ns()

◆ xmlns_cleanup()

◆ xmlns_clear_modptrs()

◆ xmlns_convert_temp_ns()

◆ xmlns_find_ns_by_module()

◆ xmlns_find_ns_by_module_str()

◆ xmlns_find_ns_by_name()

◆ xmlns_find_ns_by_name_str()

◆ xmlns_find_ns_by_prefix()

◆ xmlns_free_pmap()

◆ xmlns_free_qname()

◆ xmlns_get_mod_count()

◆ xmlns_get_modptr()

◆ xmlns_get_module()

◆ xmlns_get_ns_name()

◆ xmlns_get_ns_prefix()

◆ xmlns_ids_equal()

◆ xmlns_init()

◆ xmlns_inv_id()

◆ xmlns_nc_id()

◆ xmlns_ncn_id()

◆ xmlns_ncx_id()

◆ xmlns_new_pmap()

◆ xmlns_new_qname()

◆ xmlns_ns_id()

◆ xmlns_origin_id()

◆ xmlns_register_ns()

◆ xmlns_register_temp_ns()

◆ xmlns_set_modptrs()

◆ xmlns_unregister_ns()

◆ xmlns_wda_id()

◆ xmlns_wildcard_id()

◆ xmlns_xml_id()

◆ xmlns_xs_id()

◆ xmlns_xsi_id()

◆ xmlns_yang_id()

◆ xmlns_yin_id()

◆ xmlns_ywattrs_id()
