YANG XPath Support

YANG Specific XPath Expression Handling. More...

Collaboration diagram for YANG XPath Support:

Functions
status_t	xpath_yang_parse_path (tk_chain_t *tkc, ncx_module_t *mod, xpath_source_t source, xpath_pcb_t *pcb)
	Parse the leafref path as a leafref path. More...
status_t	xpath_yang_parse_path_ex (tk_chain_t *tkc, ncx_module_t *mod, xpath_source_t source, xpath_pcb_t *pcb, boolean logerrors, ncx_leafref_class_t *leafref_class)
	Parse the leafref path as a leafref path (extended) More...
status_t	xpath_yang_parse_path_ex2 (tk_chain_t *tkc, ncx_module_t *mod, xpath_source_t source, xpath_pcb_t *pcb, boolean logerrors, boolean is_xpath, ncx_leafref_class_t *leafref_class)
	Parse the leafref path as a leafref path (extended2) More...
status_t	xpath_yang_validate_path (ncx_module_t *mod, obj_template_t *obj, xpath_pcb_t *pcb, boolean schemainst, obj_template_t **leafobj)
	Validate the previously parsed leafref path. More...
status_t	xpath_yang_validate_path_ex (ncx_module_t *mod, obj_template_t *obj, xpath_pcb_t *pcb, boolean schemainst, obj_template_t **leafobj, boolean logerrors, boolean is_xpath)
	Validate the previously parsed leafref path (extended) More...
status_t	xpath_yang_validate_path_dev (ncx_module_t *mod, obj_template_t *obj, xpath_pcb_t *pcb, boolean schemainst, obj_template_t **leafobj, boolean logerrors, boolean is_xpath, ncx_module_t *rootmod)
	Validate the previously parsed leafref path (deviation) More...
status_t	xpath_yang_validate_xmlpath (xmlTextReaderPtr reader, xpath_pcb_t *pcb, obj_template_t *pathobj, boolean logerrors, obj_template_t **targobj)
	Validate an instance-identifier expression (XML path) within an XML PDU context. More...
status_t	xpath_yang_validate_xmlkey (xmlTextReaderPtr reader, xpath_pcb_t *pcb, obj_template_t *obj, boolean logerrors)
	Validate a key XML attribute value given in (XML Key) More...
val_value_t *	xpath_yang_make_instanceid_val (xpath_pcb_t *pcb, status_t *retres, val_value_t **deepest)
	Make a value subtree out of an instance-identifier Used by yangcli to send PDUs from CLI target parameters. More...
status_t	xpath_yang_get_namespaces (const xpath_pcb_t *pcb, ncx_prefix_info_t *nsid_array, uint32 max_nsids, uint32 *num_nsids)
	Get the namespace URI IDs used in the specified XPath expression;. More...
val_value_t *	xpath_yang_make_instanceid_str (const xmlChar *target, status_t *retres, val_value_t **targval)
	Return the instance ID string for the target object. More...

Detailed Description

YANG Specific XPath Expression Handling.

Function Documentation

xpath_yang_get_namespaces()

status_t xpath_yang_get_namespaces	(	const xpath_pcb_t *	pcb,
		ncx_prefix_info_t *	nsid_array,
		uint32	max_nsids,
		uint32 *	num_nsids
	)

Get the namespace URI IDs used in the specified XPath expression;.

usually an instance-identifier or schema-instance node but this function simply reports all the TK_TT_MSTRING tokens that have an nsid set

The XPath pcb must be previously parsed and found valid

Parameters

	pcb	the XPath parser control block to use
[out]	nsid_array	address of return array of ncx_prefix_info_t nsid_array[0..*num_nsids] returned structs used in the XPath expression
	max_nsids	number of NSIDs that can be held
[out]	num_nsids	address of return number of NSIDs written to the buffer. No duplicates will be present in the buffer *num_nsids number of NSIDs written to the array

Returns

status

Here is the call graph for this function:

xpath_yang_make_instanceid_str()

val_value_t * xpath_yang_make_instanceid_str	(	const xmlChar *	target,
		status_t *	retres,
		val_value_t **	targval
	)

Return the instance ID string for the target object.

Return a value struct from root containing all the predicate assignments in the instance identifier

Parameters

	target	string that represent XPath for the instance-identifier
[out]	retres	address of return status *retres return status for the operation
[out]	targval	address of return value *targval the target node within the returned subtree from root

Returns

malloced value node representing the instance-identifier from root to the targobj, NULL if error

Here is the call graph for this function:

xpath_yang_make_instanceid_val()

val_value_t * xpath_yang_make_instanceid_val	(	xpath_pcb_t *	pcb,
		status_t *	retres,
		val_value_t **	deepest
	)

Make a value subtree out of an instance-identifier Used by yangcli to send PDUs from CLI target parameters.

The XPath pcb must be previously parsed and found valid It must be an instance-identifier value, not a leafref path

Parameters

	pcb	the leafref parser control block, possibly cloned from from the typdef
[out]	retres	address of return status (may be NULL) *retres return status
[out]	deepest	address of return deepest node created (may be NULL) *deepest pointer to end of instance-id chain node

Returns

malloced value subtree representing the instance-identifier in internal val_value_t data structures

Here is the call graph for this function:

Here is the caller graph for this function:

xpath_yang_parse_path()

status_t xpath_yang_parse_path	(	tk_chain_t *	tkc,
		ncx_module_t *	mod,
		xpath_source_t	source,
		xpath_pcb_t *	pcb
	)

Parse the leafref path as a leafref path.

DOES NOT VALIDATE PATH NODES USED IN THIS PHASE A 2-pass validation is used in case the path expression is defined within a grouping. This pass is used on all objects, even in groupings

Error messages are printed by this function!! Do not duplicate error messages upon error return

Parameters

	tkc	parent token chain (may be NULL)
	mod	module in progress
	source	context for this expression XP_SRC_LEAFREF or XP_SRC_INSTANCEID
[in,out]	pcb	initialized xpath parser control block for the leafref path use xpath_new_pcb to initialize before calling this fn. The pcb->exprstr field must be set pcb->tkc is filled and then validated for well-formed leafref or instance-identifier syntax

Returns

status

Here is the call graph for this function:

Here is the caller graph for this function:

xpath_yang_parse_path_ex()

status_t xpath_yang_parse_path_ex	(	tk_chain_t *	tkc,
		ncx_module_t *	mod,
		xpath_source_t	source,
		xpath_pcb_t *	pcb,
		boolean	logerrors,
		ncx_leafref_class_t *	leafref_class
	)

Parse the leafref path as a leafref path (extended)

DOES NOT VALIDATE PATH NODES USED IN THIS PHASE A 2-pass validation is used in case the path expression is defined within a grouping. This pass is used on all objects, even in groupings

Error messages are printed by this function!! Do not duplicate error messages upon error return

Parameters

	tkc	parent token chain (may be NULL)
	mod	module in progress
	source	context for this expression XP_SRC_LEAFREF or XP_SRC_INSTANCEID
[in,out]	pcb	initialized xpath parser control block for the leafref path use xpath_new_pcb to initialize before calling this fn. The pcb->exprstr field must be set pcb->tkc is filled and then validated for well-formed leafref or instance-identifier syntax
	logerrors	TRUE to log errors FALSE to suppress error messages
[out]	leafref_class	address of return leafref class NULL if not used *leafref_class leafref classification for the expr

Returns

status

Here is the call graph for this function:

xpath_yang_parse_path_ex2()

status_t xpath_yang_parse_path_ex2	(	tk_chain_t *	tkc,
		ncx_module_t *	mod,
		xpath_source_t	source,
		xpath_pcb_t *	pcb,
		boolean	logerrors,
		boolean	is_xpath,
		ncx_leafref_class_t *	leafref_class
	)

Parse the leafref path as a leafref path (extended2)

DOES NOT VALIDATE PATH NODES USED IN THIS PHASE A 2-pass validation is used in case the path expression is defined within a grouping. This pass is used on all objects, even in groupings

Error messages are printed by this function!! Do not duplicate error messages upon error return

Parameters

	tkc	parent token chain (may be NULL)
	mod	module in progress
	source	context for this expression XP_SRC_LEAFREF or XP_SRC_INSTANCEID
	pcb	initialized xpath parser control block for the leafref path use xpath_new_pcb to initialize before calling this fn. The pcb->exprstr field must be set pcb->tkc is filled and then validated for well-formed leafref or instance-identifier syntax
	logerrors	TRUE to log errors FALSE to suppress error messages
	is_xpath	TRUE to allow predicate leafs other than keys This allows yangcli to generate content-match
[out]	leafref_class	address of return leafref class NULL if not used *leafref_class leafref classification for the expr

Returns

status

Here is the call graph for this function:

Here is the caller graph for this function:

xpath_yang_validate_path()

status_t xpath_yang_validate_path	(	ncx_module_t *	mod,
		obj_template_t *	obj,
		xpath_pcb_t *	pcb,
		boolean	schemainst,
		obj_template_t **	leafobj
	)

Validate the previously parsed leafref path.

• QNames are valid
• object structure referenced is valid
• objects are all 'config true'
• target object is a leaf
• leafref represents a single instance

A 2-pass validation is used in case the path expression is defined within a grouping. This pass is used only on cooked (real) objects

Called after all 'uses' and 'augment' expansion so validation against cooked object tree can be done

Error messages are printed by this function!! Do not duplicate error messages upon error return

Parameters

	mod	module containing the 'obj' (in progress) NULL if no object in progress
	obj	object using the leafref data type
	pcb	the leafref parser control block, possibly cloned from from the typdef
	schemainst	TRUE if ncx:schema-instance string FALSE to use the pcb->source field to determine the exact parse mode
[out]	leafobj	address of the return target object *leafobj the target leaf found by parsing the path (NO_ERR)

Returns

status

Here is the call graph for this function:

Here is the caller graph for this function:

xpath_yang_validate_path_dev()

status_t xpath_yang_validate_path_dev	(	ncx_module_t *	mod,
		obj_template_t *	obj,
		xpath_pcb_t *	pcb,
		boolean	schemainst,
		obj_template_t **	leafobj,
		boolean	logerrors,
		boolean	is_xpath,
		ncx_module_t *	rootmod
	)

Validate the previously parsed leafref path (deviation)

• QNames are valid
• object structure referenced is valid
• objects are all 'config true'
• target object is a leaf
• leafref represents a single instance

YPW-1416: add rootmod parameter to track module in progress after replacing leafref type make sure module in progress is found instead of calling check_import and reparsing

A 2-pass validation is used in case the path expression is defined within a grouping. This pass is used only on cooked (real) objects

Called after all 'uses' and 'augment' expansion so validation against cooked object tree can be done

Error messages are printed by this function!! Do not duplicate error messages upon error return

Parameters

	mod	module containing the 'obj' (in progress) NULL if no object in progress
	obj	object using the leafref data type
	pcb	the leafref parser control block, possibly cloned from from the typdef
	schemainst	TRUE if ncx:schema-instance string FALSE to use the pcb->source field to determine the exact parse mode
[out]	leafobj	address of the return target object *leafobj the target leaf found by parsing the path (NO_ERR)
	logerrors	TRUE to log errors, FALSE to suppress errors val_parse uses FALSE if basetype NCX_BT_UNION
	is_xpath	TRUE to allow predicate leafs other than keys This allows yangcli to generate content-match filters
	rootmod	root module being parsed; used during deviation processing for validating leafref; module will not get found and then duplicated

Returns

status

Here is the call graph for this function:

Here is the caller graph for this function:

xpath_yang_validate_path_ex()

status_t xpath_yang_validate_path_ex	(	ncx_module_t *	mod,
		obj_template_t *	obj,
		xpath_pcb_t *	pcb,
		boolean	schemainst,
		obj_template_t **	leafobj,
		boolean	logerrors,
		boolean	is_xpath
	)

Validate the previously parsed leafref path (extended)

• QNames are valid
• object structure referenced is valid
• objects are all 'config true'
• target object is a leaf
• leafref represents a single instance

A 2-pass validation is used in case the path expression is defined within a grouping. This pass is used only on cooked (real) objects

Called after all 'uses' and 'augment' expansion so validation against cooked object tree can be done

Error messages are printed by this function!! Do not duplicate error messages upon error return

Parameters

	mod	module containing the 'obj' (in progress) NULL if no object in progress
	obj	object using the leafref data type
	pcb	the leafref parser control block, possibly cloned from from the typdef
	schemainst	TRUE if ncx:schema-instance string FALSE to use the pcb->source field to determine the exact parse mode
[out]	leafobj	address of the return target object *leafobj the target leaf found by parsing the path (NO_ERR)
	logerrors	TRUE to log errors FALSE to suppress error messages
	is_xpath	TRUE to allow predicate leafs other than keys This allows yangcli to generate content-match

Returns

status

Here is the call graph for this function:

xpath_yang_validate_xmlkey()

status_t xpath_yang_validate_xmlkey	(	xmlTextReaderPtr	reader,
		xpath_pcb_t *	pcb,
		obj_template_t *	obj,
		boolean	logerrors
	)

Validate a key XML attribute value given in (XML Key)

an <edit-config> operation with an 'insert' attribute Check that a complete set of predicates is present for the specified list of leaf-list

Parameters

reader	XML reader to use
pcb	initialized XPath parser control block with a possibly unchecked pcb->exprstr. This function will call tk_tokenize_xpath_string if it has not already been called.
obj	list or leaf-list object associated with the pcb->exprstr predicate expression (MAY be NULL if first-pass parsing and object is not known yet – parsed in XML attribute)
logerrors	TRUE if log_error and ncx_print_errormsg should be used to log XPath errors and warnings FALSE if internal error info should be recorded in the xpath_result_t struct instead !!! use FALSE unless DEBUG mode !!!

Returns

status

Here is the call graph for this function:

xpath_yang_validate_xmlpath()

status_t xpath_yang_validate_xmlpath	(	xmlTextReaderPtr	reader,
		xpath_pcb_t *	pcb,
		obj_template_t *	pathobj,
		boolean	logerrors,
		obj_template_t **	targobj
	)

Validate an instance-identifier expression (XML path) within an XML PDU context.

Parameters

	reader	XML reader to use
	pcb	initialized XPath parser control block with a possibly unchecked pcb->exprstr. This function will call tk_tokenize_xpath_string if it has not already been called.
	pathobj	object to create identifier for
	logerrors	TRUE if log_error and ncx_print_errormsg should be used to log XPath errors and warnings FALSE if internal error info should be recorded in the xpath_result_t struct instead !!! use FALSE unless DEBUG mode !!!
[out]	targobj	address of return target object *targobj is set to the object that this instance-identifier references, if NO_ERR

Returns

status

Here is the call graph for this function:
