SIL Transactions are initiated from the main server. More...

Collaboration diagram for SIL Transaction APIs:

Data Structures
struct	agt_sil_added_edit_t
	Set Hook added edits from subsystem(s) More...

Typedefs
typedef void(*	agt_sil_get_walker_fn_t) (getcb_get2_t get2cb, const xmlChar subsys_id, status_t get_status, val_value_t *return_val)
	get walker function for processing results from remote GET transaction from 1 or more subsystems More...

typedef status_t(*	agt_sil_rpc_walker_fn_t) (const xmlChar subsys_id, status_t rpc_status, val_value_t return_val, dlq_hdr_t *saveQ)
	RPC walker function for processing results from remote GET transaction from 1 or more subsystems. More...

typedef status_t(*	agt_sil_shook_walker_fn_t) (ses_cb_t scb, rpc_msg_t msg, agt_cfg_transaction_t txcb, const xmlChar subsys_id, status_t tx_status, dlq_hdr_t *edded_editQ)
	Set Hook walker function. More...

Functions
status_t	agt_sil_init (void)
	Initialize the SIL features module (phase 2) More...

void	agt_sil_cleanup (void)
	Cleanup the SIL Features Module. More...

status_t	agt_sil_start_transaction (agt_cfg_transaction_t txcb, const xmlChar user_id, const xmlChar client_addr, const xmlChar target, boolean is_validate, boolean is_replay, boolean is_reverse_edit, boolean is_load_config, boolean is_hook_load, boolean is_hook_validate, dlq_hdr_t *editQ)
	Start Transaction Handler. More...

status_t	agt_sil_continue_start_transaction (agt_cfg_transaction_t txcb, const xmlChar user_id, const xmlChar client_addr, const xmlChar target, boolean is_replay, dlq_hdr_t *editQ)
	Continue already existed Start Transaction. More...

status_t	agt_sil_continue_transaction (const xmlChar *txid_str, agt_cbtyp_t cur_phase)
	Continue a transaction to apply or commit phase. More...

void	agt_sil_end_transaction (const xmlChar *txid_str)
	End a transaction. More...

void	agt_sil_cancel_transaction (const xmlChar *txid_str)
	Cancel and delete the transaction. More...

status_t	agt_sil_send_load_event (const xmlChar *name, boolean is_bundle, boolean is_load)
	Send a <load-event> to all subsystems. More...

status_t	agt_sil_send_stream_callback_event (const xmlChar subsys_id, const xmlChar modname, const xmlChar *stream_name, boolean all_streams, agt_not_subevent_t subevent)
	Send a "<stream-callback-event>" message to one subsystem. More...

boolean	agt_sil_edit_transaction_in_progress (void)
	Check if a SIL-SA transaction is in progress. More...

void	agt_sil_check_deleted_edits (agt_cfg_transaction_t *txcb)
	Check for deleted edits. More...

status_t	agt_sil_start_get_transaction (ses_cb_t client_scb, getcb_get2_t get2cb, xml_msg_hdr_t msg, const xmlChar *txid_str)
	Start a GET2 transaction. More...

status_t	agt_sil_get_transaction_status (const xmlChar *txid_str)
	Get the GET2 transaction status. More...

void	agt_sil_walk_get_results (const xmlChar *txid_str, agt_sil_get_walker_fn_t get_walker_fn)
	Walk the GET2 results. More...

status_t	agt_sil_walk_rpc_results (const xmlChar txid_str, agt_sil_rpc_walker_fn_t rpc_walker_fn, dlq_hdr_t saveQ)
	Walk the RPC transaction results. More...

status_t	agt_sil_walk_shook_results (ses_cb_t scb, rpc_msg_t msg, agt_cfg_transaction_t txcb, const xmlChar txid_str, agt_sil_shook_walker_fn_t shook_walker_fn)
	Walk the Set Hook results. More...

void	agt_sil_end_get_transaction (const xmlChar *txid_str)
	End a GET2 transaction. More...

void	agt_sil_set_subsys_timeout (uint32 val)
	Set the subsys-timeout parameter. More...

status_t	agt_sil_start_rpc_transaction (ses_cb_t client_scb, rpc_msg_t msg, obj_template_t obj, val_value_t actionval, const xmlChar **txid_str)
	Start an RPC transaction. More...

status_t	agt_sil_rpc_transaction_status (const xmlChar *txid_str)
	Get RPC transaction status. More...

void	agt_sil_end_rpc_transaction (const xmlChar *txid_str)
	End an RPC transaction. More...

status_t	agt_sil_handle_remote_trans_start (ses_cb_t client_scb, const xmlChar client_txid, boolean isvalidate, boolean isrollback, boolean isrunning)
	Handle a remote transaction. More...

status_t	agt_sil_transaction_complete_cb (const xmlChar *txid_str)
	SIL transaction complete callback. More...

status_t	agt_sil_get_exit_mode_edit (const xmlChar txid_str, agt_tx_type_t tx_type, val_value_t error_val, xmlChar error_path, xmlChar error_msg, boolean need_reverse_edit)
	Get the transaction exit code. More...

status_t	agt_sil_get_exit_mode (const xmlChar *txid_str, agt_tx_type_t tx_type)
	Get the transaction exit code. More...

boolean	agt_sil_last_in_transaction (const xmlChar *txid_str, ses_id_t sid)
	Check if the session is the last in the current transaction. More...

void	agt_sil_unload_module (const xmlChar *modname)
	Unload a module from the subsystem register messages so the cleanup is not attempted again during system cleanup. More...

status_t	agt_sil_bundle_walker (const xmlChar name, void cookie)
	Callback for bundles. More...

status_t	agt_sil_module_walker (const xmlChar name, void cookie)
	Callback for dynamically loaded modules. More...

status_t	agt_sil_handle_remote_commit_completeness (ses_cb_t client_scb, const xmlChar client_txid, agt_cbtyp_t cbtyp, agt_commit_type_t commit_type)
	Handle remote SIL-SA subsytem Commit Completeness callbacks. More...

boolean	agt_sil_subsys_registered (const xmlChar *subsys_id)
	Check if the subsystem has a SIL-SA service registered. More...

Detailed Description

SIL Transactions are initiated from the main server.

The local or remote SIL callbacks are invoked as needed for a transaction-in-progress.

Typedef Documentation

◆ agt_sil_get_walker_fn_t

typedef void(* agt_sil_get_walker_fn_t) (getcb_get2_t *get2cb, const xmlChar *subsys_id, status_t get_status, val_value_t *return_val)

get walker function for processing results from remote GET transaction from 1 or more subsystems

Parameters

get2cb	request get2 control block
subsys_id	subsystem ID string
get_status	operation status for this subsystem
return_val	<get-response> value for this subsystem, if any

◆ agt_sil_rpc_walker_fn_t

typedef status_t(* agt_sil_rpc_walker_fn_t) (const xmlChar *subsys_id, status_t rpc_status, val_value_t *return_val, dlq_hdr_t *saveQ)

RPC walker function for processing results from remote GET transaction from 1 or more subsystems.

Parameters

subsys_id	subsystem ID string
rpc_status	operation status for this subsystem
return_val	<rpc-response> value for this subsystem, if any
saveQ	Q to save val_value_t structs from responsess

Returns: status: any error to end the walk

◆ agt_sil_shook_walker_fn_t

typedef status_t(* agt_sil_shook_walker_fn_t) (ses_cb_t *scb, rpc_msg_t *msg, agt_cfg_transaction_t *txcb, const xmlChar *subsys_id, status_t tx_status, dlq_hdr_t *edded_editQ)

Set Hook walker function.

Set Hook walker function for processing added edit lists from remote EDIT transaction from 1 or more subsystems

Parameters

	scb	session control block invoking the callback
	msg	RPC message in progress
	txcb	transaction control block to check
	subsys_id	subsystem ID string
	tx_status	operation status for this subsystem
[out]	edded_editQ	Q of edded edits from 1 subsystem edded_editQ entries may be added

Returns: status

Function Documentation

◆ agt_sil_bundle_walker()

status_t agt_sil_bundle_walker	(	const xmlChar *	name,
		void *	cookie
	)

Callback for bundles.

Parameters

name	the bundle name
cookie	cookie passed to agt_ncx_load_for_all_bundles

Returns: status; will stop on error exit

Here is the call graph for this function:

◆ agt_sil_cancel_transaction()

void agt_sil_cancel_transaction ( const xmlChar * txid_str )

Cancel and delete the transaction.

The transaction may have any subsystems active

Parameters

txid_str transaction-id string

Here is the caller graph for this function:

◆ agt_sil_check_deleted_edits()

void agt_sil_check_deleted_edits ( agt_cfg_transaction_t * txcb )

Check for deleted edits.

Parameters

txcb	transaction in progress to check

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_cleanup()

void agt_sil_cleanup ( void )

Cleanup the SIL Features Module.

Called by the server during shutdown

Here is the call graph for this function:

◆ agt_sil_continue_start_transaction()

status_t agt_sil_continue_start_transaction	(	agt_cfg_transaction_t *	txcb,
		const xmlChar *	user_id,
		const xmlChar *	client_addr,
		const xmlChar *	target,
		boolean	is_replay,
		dlq_hdr_t *	editQ
	)

Continue already existed Start Transaction.

Used for Added by Set Hook edits. Can be called only right after Start Transaction. Using the same message as for Start Transaction

Parameters

txcb	transaction control block to check
user_id	user initiating this transaction
client_addr	IP address of client session
target	datastore target
is_replay	TRUE for <replay-config> operation; FALSE for normal edit
editQ	Q of edits to encode (Q of agt_cfg_silcall_t)

Returns: status of the operation

Here is the call graph for this function:

◆ agt_sil_continue_transaction()

status_t agt_sil_continue_transaction	(	const xmlChar *	txid_str,
		agt_cbtyp_t	cur_phase
	)

Continue a transaction to apply or commit phase.

Parameters

txid_str	transaction-id string
cur_phase	transaction callback phase to invoke

Returns: status of the operation

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_edit_transaction_in_progress()

boolean agt_sil_edit_transaction_in_progress ( void )

Check if a SIL-SA transaction is in progress.

Returns: TRUE if a transaction could be in progress; FALSE if not

Here is the caller graph for this function:

◆ agt_sil_end_get_transaction()

void agt_sil_end_get_transaction ( const xmlChar * txid_str )

End a GET2 transaction.

Parameters

txid_str transaction ID string to end

◆ agt_sil_end_rpc_transaction()

void agt_sil_end_rpc_transaction ( const xmlChar * txid_str )

End an RPC transaction.

Parameters

txid_str transaction ID string to end

◆ agt_sil_end_transaction()

void agt_sil_end_transaction ( const xmlChar * txid_str )

End a transaction.

Parameters

txid_str transaction-id string

Here is the caller graph for this function:

◆ agt_sil_get_exit_mode()

status_t agt_sil_get_exit_mode	(	const xmlChar *	txid_str,
		agt_tx_type_t	tx_type
	)

Get the transaction exit code.

YPW-1545: memory usage malfanction

Get the reason code for exiting YControl IO mode Can only be called once for each txid value!!! Causes stored txid_in_progress record to be deleted and txid_doneQ will be also cleaned up

Checks the status of the transaction phase that completed: The agt_ncxserver_run loop exited because the timer expired or the phase completed OK, or 1 of the subsystems responded with an error

Parameters

txid_str	transaction-id string
tx_type	transaction type (GET\|HOOK\|RPC)

Returns: status of the operation

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_get_exit_mode_edit()

status_t agt_sil_get_exit_mode_edit	(	const xmlChar *	txid_str,
		agt_tx_type_t	tx_type,
		val_value_t **	error_val,
		xmlChar **	error_path,
		xmlChar **	error_msg,
		boolean *	need_reverse_edit
	)

Get the transaction exit code.

YPW-1872: SIL-SA custom error messages support

Get the reason code for exiting YControl IO mode For EDIT requests only

Checks the status of the transaction phase that completed: The agt_ncxserver_run loop exited because the timer expired or the phase completed OK, or 1 of the subsystems responded with an error

Parameters

	txid_str	transaction-id string. Find this transaction.
	tx_type	transaction type (EDIT). Find this transaction type.
[out]	error_val	address of newval or curval causing error *error_val set to the value causing the error
[out]	error_path	address of error string to use in error response; *error_path set to the error path string to use in the error report.
[out]	error_msg	pointer to error message string to use in error response; *error_msg set to the error message string to use.
[out]	need_reverse_edit	address of return address flag *need_reverse_edit TRUE if need for reverse edit detected

Returns: status of the operation

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_get_transaction_status()

status_t agt_sil_get_transaction_status ( const xmlChar * txid_str )

Get the GET2 transaction status.

Parameters

txid_str transaction-id string

Returns: status of the GET transaction that completed The agt_ncxserver_run loop exited because the timer expired or the phase completed OK

Here is the caller graph for this function:

◆ agt_sil_handle_remote_commit_completeness()

status_t agt_sil_handle_remote_commit_completeness	(	ses_cb_t *	client_scb,
		const xmlChar *	client_txid,
		agt_cbtyp_t	cbtyp,
		agt_commit_type_t	commit_type
	)

Handle remote SIL-SA subsytem Commit Completeness callbacks.

Parameters

client_scb	session to use
client_txid	server transaction ID string to use
cbtyp	callback phase enum
commit_type	commit type; only if phase is Commit

Returns: status; will stop on error exit

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_handle_remote_trans_start()

status_t agt_sil_handle_remote_trans_start	(	ses_cb_t *	client_scb,
		const xmlChar *	client_txid,
		boolean	isvalidate,
		boolean	isrollback,
		boolean	isrunning
	)

Handle a remote transaction.

Parameters

client_scb	session to use
client_txid	Server transaction ID string to use
isvalidate	TRUE if this is Transaction is for Validate
isrollback	TRUE if this is Transaction for Rollback or Load
isrunning	TRUE if running datastore is being modified

Returns: status of the operation

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_init()

status_t agt_sil_init ( void )

Initialize the SIL features module (phase 2)

Returns: status of the initialization procedure

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_last_in_transaction()

boolean agt_sil_last_in_transaction	(	const xmlChar *	txid_str,
		ses_id_t	sid
	)

Check if the session is the last in the current transaction.

Figure out if the specified session ID is the only one in the specified transaction. If so, the caller will exit the agt_ncxserver_run_ycontrol function. If the SID is not involved in this transaction, or other subsystems are involved besides the specified SID, then the function will return FALSE

Parameters

txid_str	transaction ID string to check
sid	session ID to check

Returns: TRUE if this is last or only session in the specified transaction
FALSE otherwise

Here is the call graph for this function:

◆ agt_sil_module_walker()

status_t agt_sil_module_walker	(	const xmlChar *	name,
		void *	cookie
	)

Callback for dynamically loaded modules.

Parameters

name	the module name
cookie	cookie passed to agt_ncx_load_for_all_bundles

Returns: status; will stop on error exit

Here is the call graph for this function:

◆ agt_sil_rpc_transaction_status()

status_t agt_sil_rpc_transaction_status ( const xmlChar * txid_str )

Get RPC transaction status.

Parameters

txid_str transaction-id string

Returns: status of the RPC transaction that completed. The agt_ncxserver_run loop exited because the timer expired or the phase completed OK

Here is the caller graph for this function:

◆ agt_sil_send_load_event()

status_t agt_sil_send_load_event	(	const xmlChar *	name,
		boolean	is_bundle,
		boolean	is_load
	)

Send a <load-event> to all subsystems.

TBD: send to specific subsystems

Parameters

name	name of module or bundle
is_bundle	TRUE if name is a bundle; FALSE if a module
is_load	TRUE if load event; FALSE if unload event

Returns: status of the operation

Here is the call graph for this function:

◆ agt_sil_send_stream_callback_event()

status_t agt_sil_send_stream_callback_event	(	const xmlChar *	subsys_id,
		const xmlChar *	modname,
		const xmlChar *	stream_name,
		boolean	all_streams,
		agt_not_subevent_t	subevent
	)

Send a "<stream-callback-event>" message to one subsystem.

Parameters

subsys_id	name of subsystem to get this event
modname	name of module that registered callback
stream_name	stream that this callback is about
all_streams	flag used to register entry
subevent	subevent code to use

Returns: status of the operation

Here is the call graph for this function:

◆ agt_sil_set_subsys_timeout()

void agt_sil_set_subsys_timeout ( uint32 val )

Set the subsys-timeout parameter.

Parameters

val	value to use for timeout in seconds

Here is the call graph for this function:

◆ agt_sil_start_get_transaction()

status_t agt_sil_start_get_transaction	(	ses_cb_t *	client_scb,
		getcb_get2_t *	get2cb,
		xml_msg_hdr_t *	msg,
		const xmlChar **	txid_str
	)

Start a GET2 transaction.

Parameters

	client_scb	client session requesting GET operation
	get2cb	get2 control block to use
	msg	message header to use
[out]	txid_str	address of return transaction ID string *txid_str backptr to transaction ID string

Returns: status of the operation

Here is the call graph for this function:

◆ agt_sil_start_rpc_transaction()

status_t agt_sil_start_rpc_transaction	(	ses_cb_t *	client_scb,
		rpc_msg_t *	msg,
		obj_template_t *	obj,
		val_value_t *	actionval,
		const xmlChar **	txid_str
	)

Start an RPC transaction.

Parameters

	client_scb	session control block to use
	msg	rpc message
	obj	RPC object being invoked
	actionval	action value in use if ACTION
[out]	txid_str	address of return transaction ID string *txid_str backptr to transaction ID string

Returns: status of the operation

Here is the call graph for this function:

◆ agt_sil_start_transaction()

status_t agt_sil_start_transaction	(	agt_cfg_transaction_t *	txcb,
		const xmlChar *	user_id,
		const xmlChar *	client_addr,
		const xmlChar *	target,
		boolean	is_validate,
		boolean	is_replay,
		boolean	is_reverse_edit,
		boolean	is_load_config,
		boolean	is_hook_load,
		boolean	is_hook_validate,
		dlq_hdr_t *	editQ
	)

Start Transaction Handler.

Parameters

txcb	transaction control block to use
user_id	user initiating this transaction
client_addr	IP address of client session
target	datastore target
is_validate	TRUE for <validate> operation FALSE for normal edit
is_replay	TRUE for <replay-config> operation FALSE for normal edit
is_reverse_edit	TRUE for undo of commited edit(s) in the form of a new reverse edit FALSE for normal edit
is_load_config	TRUE for <load-config> operation FALSE for normal edit
is_hook_load	TRUE if this is the LOAD operation
is_hook_validate	TRUE if this is validate OP
editQ	Q of edits to encode (Q of agt_cfg_silcall_t)

Returns: status of the operation

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_subsys_registered()

boolean agt_sil_subsys_registered ( const xmlChar * subsys_id )

Check if the subsystem has a SIL-SA service registered.

Parameters

subsys_id subsys identifier to check

Returns: TRUE if registered; FALSE if not registered

◆ agt_sil_transaction_complete_cb()

status_t agt_sil_transaction_complete_cb ( const xmlChar * txid_str )

SIL transaction complete callback.

Parameters

txid_str transaction ID string to end

Here is the call graph for this function:

Here is the caller graph for this function:

◆ agt_sil_unload_module()

void agt_sil_unload_module ( const xmlChar * modname )

Unload a module from the subsystem register messages so the cleanup is not attempted again during system cleanup.

Parameters

modname module name to find and remove register message

◆ agt_sil_walk_get_results()

void agt_sil_walk_get_results	(	const xmlChar *	txid_str,
		agt_sil_get_walker_fn_t	get_walker_fn
	)

Walk the GET2 results.

Check the results of the get retrieval from each subsystem The walker function is called for each subsystem

Parameters

txid_str	get transaction IS string
get_walker_fn	get results walker function

◆ agt_sil_walk_rpc_results()

status_t agt_sil_walk_rpc_results	(	const xmlChar *	txid_str,
		agt_sil_rpc_walker_fn_t	rpc_walker_fn,
		dlq_hdr_t *	saveQ
	)

Walk the RPC transaction results.

Check the results of the RPC retrieval from each subsystem The walker function is called for each subsystem

Parameters

txid_str	get transaction IS string
rpc_walker_fn	RPC results walker function
saveQ	Q to save the results

Returns: status

◆ agt_sil_walk_shook_results()

status_t agt_sil_walk_shook_results	(	ses_cb_t *	scb,
		rpc_msg_t *	msg,
		agt_cfg_transaction_t *	txcb,
		const xmlChar *	txid_str,
		agt_sil_shook_walker_fn_t	shook_walker_fn
	)

Walk the Set Hook results.

Check the results of the RPC retrieval from each subsystem The walker function is called for each subsystem

Parameters

scb	session control block invoking the callback
msg	RPC message in progress
txcb	transaction control block to check
txid_str	get transaction IS string
shook_walker_fn	Hook results walker function

Returns: status

Data Structures

Typedefs

Functions

Detailed Description

Typedef Documentation

◆ agt_sil_get_walker_fn_t

◆ agt_sil_rpc_walker_fn_t

◆ agt_sil_shook_walker_fn_t

Function Documentation

◆ agt_sil_bundle_walker()

◆ agt_sil_cancel_transaction()

◆ agt_sil_check_deleted_edits()

◆ agt_sil_cleanup()

◆ agt_sil_continue_start_transaction()

◆ agt_sil_continue_transaction()

◆ agt_sil_edit_transaction_in_progress()

◆ agt_sil_end_get_transaction()

◆ agt_sil_end_rpc_transaction()

◆ agt_sil_end_transaction()

◆ agt_sil_get_exit_mode()

◆ agt_sil_get_exit_mode_edit()

◆ agt_sil_get_transaction_status()

◆ agt_sil_handle_remote_commit_completeness()

◆ agt_sil_handle_remote_trans_start()

◆ agt_sil_init()

◆ agt_sil_last_in_transaction()

◆ agt_sil_module_walker()

◆ agt_sil_rpc_transaction_status()

◆ agt_sil_send_load_event()

◆ agt_sil_send_stream_callback_event()

◆ agt_sil_set_subsys_timeout()

◆ agt_sil_start_get_transaction()

◆ agt_sil_start_rpc_transaction()

◆ agt_sil_start_transaction()

◆ agt_sil_subsys_registered()

◆ agt_sil_transaction_complete_cb()

◆ agt_sil_unload_module()

◆ agt_sil_walk_get_results()

◆ agt_sil_walk_rpc_results()

◆ agt_sil_walk_shook_results()
